NSF Certified Filter Tank 80102 80-100T/H 6'' Flange 150psi CE
NSF Certified Filter Tank: High-Quality Composite Material for Safe Water Treatment
NSF certified filter tank is a safe and reliable choice in the water treatment field due to its strict quality standards and excellent material performance. It has passed NSF-61 and CE certifications, performing outstandingly in industries with high water quality requirements such as food, beverage, and medical, providing stable filtration support for various water treatment systems.
Core Parameters
This NSF certified filter tank has an imperial size of 80102, with a diameter and height of φ2000×2600mm. It adopts a Top&Bottom Opening 6" Flange design, and the Design Flow Rate is 80.0～100.0T/H, meeting the flow requirements of medium and large water treatment scenarios.
Size(inch) | Diam&Height(mm) | Opening(inch) | Design Flow Rate(T/H) |
80102 | φ2000×2600 | Top&Bottom Opening 6" Flange | 80.0～100.0 |
8520/
Materials and Construction
Tank materials: The outer shell is made of fiberglass filament winding, with an integrated seamless PE liner. The liner thickness ranges from 0.15”(3.0mm) to 0.3”(7.6mm) according to the tank diameter, ensuring tightness and corrosion resistance.
Base and openings: The base is made of fiberglass or reinforced polypropylene; openings are diverse, with 2.5" and 4" openings using reinforced plastic threads, and 6-inch flanges made of aluminum alloy, adapting to different connection needs.
Packaging and Features
Solid packaging: Small fiberglass tanks are packed in individual cartons, large sizes on pallets, with reinforced packaging for international transportation. Each carton or pallet is marked for easy identification.
Key features: Made of high-performance composite materials, fiberglass filament winding ensures 100% corrosion resistance; pressure tanks cover diameters from 6 inches to 63 inches and heights from 10 inches to 86 inches, with a wide adaptation range; all pressure tanks undergo 100% hydraulic testing before delivery to ensure quality.
Operating Conditions and Certifications
Operating conditions: Working pressure up to 150psi(10.5bar), working temperature range from 50°F(65°C) to 120°F(49°C) (flange tanks), adapting to various working conditions.
Authoritative certifications: Passed NSF-61 certification (related to drinking water system component safety) and CE certification, meeting international safety standards.
Industrial Application Case
A high-end drinking water plant suffered multiple product recalls due to microbial contamination in water, losing over 500,000 yuan. After introducing the NSF certified filter tank (Model 80102), its 80.0～100.0T/H flow rate met production line needs. NSF certification ensured filtered water met drinking water standards, completely solving microbial issues. The tank's corrosion resistance extended maintenance intervals to 2 years, saving 80,000 yuan in annual maintenance costs. Product qualification rate rose to 100%, with annual sales increasing by 3 million yuan.
