DuPont IntegraFlux SFD 2880 XP Ultrafiltration Module – Advanced Filtration Technology for Superior Performance
DuPont Ultrafiltration Membranes SFP 2880XP / SFD 2880XP with High-Efficiency Filtration PerformanceDow Ultrafiltration Membranes, known for their advanced technology, offer superior filtration capabilities, exceptional durability, and unmatched reliability for water treatment processes.Key Features
DuPont Ultrafiltration Membranes SFP 2880XP / SFD 2880XP with High-Efficiency Filtration Performance
Dow Ultrafiltration Membranes, known for their advanced technology, offer superior filtration capabilities, exceptional durability, and unmatched reliability for water treatment processes.
Key Features:
High Filtration Efficiency:
The finely engineered membrane structure effectively removes impurities, microorganisms, and contaminants from water, ensuring the highest standards of purity.
Exceptional Durability:
These membranes provide outstanding resistance to wear and tear, offering long-lasting performance in even the most challenging environments.
Stable Filtration Performance:
The membranes deliver consistent and reliable filtration results, maintaining high accuracy across various water qualities and operational conditions.
Energy Efficiency:
Designed for low energy consumption, these membranes help reduce operating costs while supporting environmentally sustainable water treatment processes.
Versatile Applications:
Ideal for drinking water purification, industrial wastewater treatment, and food & beverage processes, Dow Ultrafiltration Membranes cater to a wide range of water treatment needs.
Innovation and Research:
Dow is committed to continuous innovation and research, ensuring that their ultrafiltration membranes are always at the forefront of water treatment technology.
Comprehensive Product Range:
The Dow Ultrafiltration Membrane portfolio includes a variety of solutions designed to meet specific water treatment requirements across different sectors.
Technical Support and Expertise:
With extensive technical support, Dow ensures that clients receive not only high-quality membranes but also expert guidance to optimize water treatment processes.
Product Specifications:
| Model | Type | Membrane Area | Module Volume | Weight (Empty/Water Filled) |
|---|---|---|---|---|
| SFD-2880XP | NSF/ANSI 61 and 419 | 77 m² (829 ft²) | 39 Liters (10.3 Gallons) | 61 kg (100 lbs) / 135 kg (220 lbs) |
Module Dimensions and Properties:
| Dimension | Length (L) | Length (L1) | Length (L2) | Length (L3) | Diameter (D) | Width (W1) | Width (W2) |
|---|---|---|---|---|---|---|---|
| SI (mm) | 2360 | 2000 | 2130 | 2320 | 225 | 180 | 342 |
Operating Parameters:
| Parameter | SI Units | US Units |
|---|---|---|
| Filtrate Flux @ 25ºC | 40-110 l/m²/h | 24-65 gfd |
| Flow Range | 2.0 – 8.5 m³/hr | 8.8 – 37.4 gpm |
| Temperature | 1-40ºC | 34-104ºF |
| Max. Inlet Module Pressure (@ 20ºC) | 6.25 bar | 90.65 psi |
| Max. Operating TMP | 2.1 bar | 30.5 psi |
| Max. Operating Air Scour Flow | 12 nm³/hr | 7.1 scfm |
| Max. Backwash Pressure | 2.5 bar | 36 psi |
| Operating pH | 2-11 | |
| NaOCl (Max.) | 2,000 mg/L | |
| Particle Size (Max.) | 300 µm | |
| Flow Configuration | Outside-in, Dead End Flow | |
| Expected Filtrate Turbidity | ≤0.1 NTU | |
| Expected Filtrate SDI | ≤2.5 |
Additional Specifications:
Brand: DuPont Ultrafiltration
Replaced by: IntegraTec XP 77
Turbidity (NTU): 0.1
Max Pressure (psi): 68.9
Max Pressure (bar): 4.75
Max Temperature (°C): 41
Max Temperature (°F): 104
Membrane Active Area (ft²): 829
Membrane Active Area (m²): 77
Flow (gpm): 37.4
Flow (m³/day): 204
pH Range: 2-11
Volume (L): 39
Applications:
Ultra-pure water production
Beverage production
Boiler water treatment
For more application cases, please click here: Industries
