SFD-2880 (UF ultrafiltration membrane 77m2) ultrafiltration membrane uf membrane
The following is a description of SFD-2880 (UF Ultrafiltration Membrane 77m²) generated for you:
SFD-2880 is a high-performance UF ultrafiltration membrane with a membrane area of 77m². It is manufactured using advanced technology and high-quality materials and has excellent filtration performance. Its nominal pore size of 0.03 microns can effectively remove bacteria, viruses and particulate matter including colloids, providing reliable protection for downstream processes such as RO. The PVDF polymer hollow fiber of this ultrafiltration membrane has high strength and good chemical resistance, ensuring a long service life. In addition, the hydrophilic PVDF fiber makes cleaning easy and has good wettability, which helps to maintain stable performance over a long period of time. The unique Outside In flow configuration has a high tolerance for feed solids and reduces the need for pretreatment processes. At the same time, the design of the U-PVC shell also saves the cost of expensive pressure vessels. The SFD-2880 ultrafiltration membrane is suitable for a variety of water treatment applications and is your ideal choice for efficient and economical filtration.
|
|
|
|
|
|
| Weight |
|
|
| Membrane Area | Volume | (empty/water filled) |
| Product | Type |
| m2 | ft2 | liters | gallons | kg/lbs | kg/lbs |
| SFP-2860 | Industrial |
| 51 | 549 | 35 | 9.3 | 48/83 | 106/183 |
| SFD-2860 | NSF/ANSI 61 |
| 51 | 549 | 35 | 9.3 | 48/84 | 106/184 |
| Drinking Water |
|
|
|
|
|
|
|
| SFP-2880 | Industrial |
| 77 | 829 | 39 | 10.3 | 61/100 | 135/220 |
| SFD-2880 | NSF/ANSI 61 |
| 77 | 829 | 39 | 10.3 | 61/101 | 135/221 |
| Drinking Water |
|
|
|
|
|
|
|
DUPONT UF membrane structure external pressure hollow fiber |
|
Membrane material | PVDF (polyvinylidene fluoride) |
Housing material | UPVC (polyvinyl chloride) |
Nominal membrane pore diameter | 0.03mm |
Membrane outer/inner diameter | 1.3mm/0.7mm |
Maximum water inlet pressure | ≤ 6.0 bar (87 psi) |
Water extraction flux | 40–120 LMH (24 – 70 FGD) |
Maximum TMP tolerated | ≤2.1 bar (30psi) |
Operating | pH 2 - 11 |
Maximum allowable backwash pressure | 2.5 bar (36psi) |
Maximum allowable NaOCl concentration (cleaning) | 2000 ppm |
Membrane model | Nominal membrane area m2 (ft2) | Membrane weight (wet) kg (1b) | Membrane size (mm) |
SFP2660 | 33(335) | 41(90) | 165·1856 |
SFP2860 | 51(549) | 83(183) | 225·1860 |
For application cases, please click:https://www.fgwater.com/Industries/
