Dupont Dow's Ultrafiltration Membrane Modules
DuPont IntegraTec XP 77 IP IG Ultrafiltration Module - High-Efficiency PVDF Membrane for Industrial Applications
DuPont Ultrafiltration IntegraTec XP 77 IP IG Ultrafiltration ModuleBrand: DuPont UltrafiltrationType: Hollow FiberPore Size: 0.03 µmMax Temperature: 41°C (104°F)Membrane Active Area: 77.0 m² (829 ft²)Flow Rate: 37.4 gpm (204 m³/day)pH Range: 2-11Particle Size: 300 µmApplication: Drinking wat
DuPont Ultrafiltration IntegraTec XP 77 IP IG Ultrafiltration Module
Brand: DuPont Ultrafiltration
Type: Hollow Fiber
Pore Size: 0.03 µm
Max Temperature: 41°C (104°F)
Membrane Active Area: 77.0 m² (829 ft²)
Flow Rate: 37.4 gpm (204 m³/day)
pH Range: 2-11
Particle Size: 300 µm
Application: Drinking water, utility water, wastewater treatment
Product Overview:
The DuPont Ultrafiltration IntegraTec XP 77 IP IG Ultrafiltration Module utilizes Dow's cutting-edge PVDF (Polyvinylidene Fluoride) hollow fiber membrane technology, providing outstanding performance in water treatment. With superior cleanability, low chemical consumption, high recovery rates, and excellent mechanical and chemical resistance, these modules are ideal for:
RO (Reverse Osmosis) pre-treatment
Drinking water production
Wastewater treatment
The SFP/SFD series provides a proven solution, with a long track record of installations worldwide. Additionally, the pre-engineered, modular IntegraPac™ skid offers a streamlined, ready-to-assemble solution for efficient installation.
With DOW IntegraFlo™ modules, these ultra-large surface area products are designed to address the industry's ongoing demand to reduce water costs.
Specifications
| Specification | Value |
|---|---|
| Brand | DuPont Ultrafiltration |
| Type | Hollow Fiber |
| Pore Size (µm) | 0.03 |
| Max Temperature (°C) | 41 |
| Max Temperature (°F) | 104 |
| Membrane Active Area (ft²) | 829 |
| Membrane Active Area (m²) | 77.0 |
| Flow Rate (gpm) | 37.4 |
| pH Range | 2-11 |
| Particle Size (µm) | 300 |
| Dimensions (Length) | 92.9 inches (2360 mm) |
| Weight | 81 kg (179 lbs) |
| Applications | Drinking water, utility water |
For more details or to inquire about purchasing, please visit our Contact Us page or email us at [email protected].
For more about DuPont Ultrafiltration Membrane Modules, visit here.
