Ionpure IP-LXM18Z-5 CEDI Module, 2.0–3.1 m³/h Design Flow
1.Product OverviewThe Ionpure IP-LXM18Z-5 is an industrial continuous electrodeionization (CEDI) module that produces a continuous flow of high-purity deionized water. It is intended for applications including boiler makeup water for power plants, water for hydrocarbon processing, and water fo
1. Product Overview
The Ionpure IP-LXM18Z-5 is an industrial continuous electrodeionization (CEDI) module that produces a continuous flow of high-purity deionized water. It is intended for applications including boiler makeup water for power plants, water for hydrocarbon processing, and water for chemical processing.
2. PRODUCT SPECIFICATIONS
Item | Specification |
Brand | Ionpure |
Model | IP-LXM18Z-5 |
Product type | Continuous electrodeionization (CEDI) module |
Ordering part number | W3T17297 |
Dimension L | 488.2 mm (19.22 in); tolerance ±6.4 mm (±0.25 in) |
Dimension C | 353.8 mm (13.93 in); tolerance ±3.2 mm (±0.13 in) |
Shipping weight | 99 kg (217 lb), including shipping crate |
Operating weight | 74 kg (163 lb) |
3. OPERATING PARAMETERS
Parameter | Value / Range |
Minimum flow rate | 1.02 m³/h (4.5 gpm) |
Design flow rate | 2.0–3.1 m³/h (9.0–13.5 gpm) |
Feed water source | RO permeate |
Feed water conductivity equivalent, including CO₂ and silica | < 40 μS/cm |
Feed water temperature | 5–45°C (41–113°F) |
Inlet pressure | 1.4–6.9 bar (20–100 psig) |
Feed water pH | 4–11 |
Maximum total chlorine, as Cl₂ | < 0.05 ppm |
Iron, as Fe | < 0.01 ppm |
Manganese, as Mn | < 0.01 ppm |
Sulfide, S²⁻ | < 0.01 ppm |
Total hardness, as CaCO₃ | < 1.0 ppm |
Dissolved organics, TOC as C | < 0.5 ppm |
Silica, SiO₂ | < 1.0 ppm |
Installation environment | Indoors, away from direct sunlight; maximum ambient temperature 45°C (113°F) |
The water quality limits above are feed-water requirements for operation.
4. Key Features & Benefits
Continuous production: Provides a continuous flow of high-purity deionized water without chemical regeneration.
2.0–3.1 m³/h design flow rate: Supports module selection for systems requiring 9.0–13.5 gpm of design flow.
RO permeate feed: RO permeate is the specified feed-water source, subject to the feed-water limits listed below.
Improved chlorine tolerance: The LX-Z series is designed with improved chlorine tolerance; feed-water total chlorine (as Cl₂) must be < 0.05 ppm.
5. Key Applications
Boiler makeup water for power plants
Water for hydrocarbon processing
Water for chemical processing
