10000GPD Reverse Osmosis Water Treatment Equipment - High-Efficiency Desalination & Purification System

Powerful 10000GPD Reverse Osmosis Water Treatment Equipment for Diverse ApplicationsDiscover our advanced 10000GPD Reverse Osmosis Water Treatment Equipment, engineered to deliver superior water purification and desalination with a desalination rate of up to 99.7%. This high-performance system combi

Category: Product System

10000GPD Reverse Osmosis Water Treatment Equipment - High-Efficiency Desalination & Purification System

Powerful 10000GPD Reverse Osmosis Water Treatment Equipment for Diverse Applications

Discover our advanced 10000GPD Reverse Osmosis Water Treatment Equipment, engineered to deliver superior water purification and desalination with a desalination rate of up to 99.7%. This high-performance system combines cutting-edge technology with robust design, making it ideal for commercial, industrial, pharmaceutical, and drinking water applications. Originating from China, our system holds CE/NSF certifications, ensuring compliance with international quality standards.

Key Technical Parameters at a Glance

Parameter	Specification
Capacity	10000GPD (45.4m³/day)
Recovery Rate	65-75%
Desalination Rate	99-99.7%
Feed TDS Limit	<1000 ppm
Operating Temperature	5-35°C
pH Range	4-9
Membrane Type	Vontron, Hydranautics, or DOW 4040 membranes
Material	SS304/SS316L stainless steel, carbon steel
Power Supply	380V/415V/220V (customizable)
Design	Skid-mounted for easy installation

Why Choose Our 10000GPD RO System?

Our reverse osmosis system stands out with its innovative features, designed to maximize efficiency while minimizing operational costs:

High-Performance Membranes: Equipped with ultra-low energy membranes (Vontron, Hydranautics, or DOW 4040) for superior contaminant removal and long lifespan.
Energy-Efficient Design: Multi-stage stainless steel booster pump (CNP/Grundfos) reduces energy consumption by up to 30% compared to standard systems.
Intelligent Control System: Micro-computer controller with LCD backlit display, TDS monitoring, and low-pressure alarm for automated operation.
Robust Construction: SS316L stainless steel components and FRP membrane housings ensure corrosion resistance and durability.
Flexible Configuration: Skid-mounted design allows easy integration into existing systems, with customizable voltage and flow rates.

Applications: Versatile Solutions for Various Industries

Our 10000GPD Reverse Osmosis Water Treatment Equipment is suitable for a wide range of applications:

Water Purification: Produces high-purity water for drinking, commercial use, and industrial processes.
Desalination: Efficiently converts seawater (SWRO) and brackish water (BWRO) into potable water.
Pharmaceutical Industry: Meets strict water quality standards for drug manufacturing and laboratory use.
Food & Beverage: Ensures clean water for production, cleaning, and packaging processes.
Industrial Processes: Provides treated water for cooling towers, boilers, and manufacturing operations.

System Specifications & Performance

The TR/BR series offers scalable configurations to meet different flow requirements. Below is a detailed breakdown for the 10000GPD model (TR/BR-6140):

Model	TR/BR-6140
Permeate Flow	10,800 GPD (40,882 LPD) / 7.50 GPM (28.39 LPM)
Vessel Array	2:02:02
Vessel Quantity	6
Membrane Quantity	6
Membrane Size	4040
Nominal TDS Rejection	98.5%
Pump Type	Multi-stage stainless steel
Motor HP	3 HP
System Dimensions	32 x 26 x 60 in (83.82 x 66.04 x 154.94 cm)
Approximate Weight	470 lbs (213.19 kg)

Operating Limits & Technical Considerations

To ensure optimal performance, please adhere to the following operating parameters:

Temperature Range: 5-35°C (41-95°F) – note that low temperatures may reduce flow rates.
Feed Water Quality: SDI <3, TSS <5 mg/L, free chlorine 0 mg/L, dissolved iron <0.1 mg/L.
Pressure Limits: Maximum operating pressure 200 psi (14 bar), minimum feed pressure 45 psi (3.1 bar).
pH Range: Continuous operation 4-9; cleaning range 1-13 (30-minute limit).

Note: High TDS levels or non-standard feed water conditions may require system customization. Contact us for application-specific projections.

Easy Installation & Maintenance

Our skid-mounted design simplifies installation, with all components pre-assembled and tested. Standard features include:

Pre-treatment lockout and tank level input for automated operation.
Permeate and concentrate flow meters for precise monitoring.
5-micron sediment pre-filter and glycerin-filled pressure gauges.
Dual chemical pump outlets for optional anti-scalant or pH adjustment.

Optional upgrades are available to enhance functionality, such as:

Filmtec® LCLE membrane elements for higher recovery rates.
pH controller and permeate sample valves for detailed water quality analysis.
Stainless steel membrane housings for aggressive water conditions.

Ordering & Technical Support

Minimum Order Quantity: 1 set
Delivery Time: 15-30 days
Payment Terms: T/T, Western Union, PayPal
Warranty: 1 year on parts and labor

For customized solutions or detailed technical specifications, contact our expert team:
[email protected]
https://www.fgwater.com/Contact-Us/

Explore Related Products

Invest in our 10000GPD Reverse Osmosis Water Treatment Equipment for reliable, high-performance water purification that meets your most demanding needs. With advanced technology and global certification, our system delivers consistent results for years to come.
