4TPH 25200GPD Industrial Reverse Osmosis Water Treatment System | Fenigal Brand OEM Available

Product Description:This 4 Ton per Hour (25200 Gallons Per Day) Reverse Osmosis Water Treatment System is designed for industrial water purification applications. Utilizing advanced RO membrane technology, it effectively removes dissolved solids, organics, colloidal particles, color, nitrate, and ba

Category: Product System

Product Description:
This 4 Ton per Hour (25200 Gallons Per Day) Reverse Osmosis Water Treatment System is designed for industrial water purification applications. Utilizing advanced RO membrane technology, it effectively removes dissolved solids, organics, colloidal particles, color, nitrate, and bacteria from feed water. It is widely used in industries such as food and beverage processing, electronics manufacturing, and pharmaceuticals. The system features a modular skid-mounted design for easy installation and flexible operation. It is compatible with various well-known RO membrane brands like DOW, Vontron, and Hydranautics to meet diverse customer needs.

Process Flow:
Raw Water → Raw Water Tank → Raw Water Pump → Quartz Sand Filter → Activated Carbon Filter → Softener (Optional) → Precision Filter → High Pressure Pump → RO System → Pure Water Tank → Booster Pump → UV Sterilizer / Ozone Generator (Optional) → Water Distribution Points

Product Specifications:

Parameter	Description
Model Number	RO-4TPH, 1-17
Permeate Flow	4,000L/h (25200GPD)
Recovery Rate	60~65%
Desalination Rate	99%~99.7%
Feed Water TDS	<2,000 ppm
Water Temperature	5~35˚C
Design	Skid-Mounted
Material	SS304 / SS316L Stainless Steel, Carbon Steel
Control System	Manual / Electronic / PLC
RO Membranes	Vontron, Hydranautics, DOW (4040 Model)
Membrane Housing	8080 Stainless Steel
Raw Water & High Pressure Pumps	CNP Brand
Filter System	3 FRP Vessels: Sand Filter, Carbon Filter, Softener
Security Filter	Stainless Steel Housing with 5μm PP Cartridge
Power Supply	380V / 415V / 220V (Customizable)
Power Consumption	Approx. 5.0 kW
Certifications	CE, NSF, etc.
Place of Origin	China
Brand Name	Fenigal or OEM
Minimum Order Quantity	1 Set
Packaging	Standard Export Wooden Crate/Carton or Film-Wrapped Naked
Delivery Time	15~30 Days
Payment Terms	T/T, PayPal, Western Union, etc.
Monthly Supply Capacity	50 Sets/Month

For quotations, technical support, or to become a distributor, please contact us for more information.
