3000 GPD Skid-Mounted Chemical Dosing System for Water Reuse & Food Processing

Key SpecificationsTechnology:Industrial & Commercial Reverse Osmosis (RO)Design:Skid-Mounted, CompactCapacity:3000 GPD (Customizable 1500–9000 GPD)Permeate Flow:0.25–1.5 m³/h (4–70 TPD)Feed Water TDS:<1500 ppmDesalination Rate:99%–99.8%pH Range:4

Category: Product System
3000 GPD Skid-Mounted Chemical Dosing System for Water Reuse & Food Processing

Key Specifications

Technology: Industrial & Commercial Reverse Osmosis (RO)

Design: Skid-Mounted, Compact

Capacity: 3000 GPD (Customizable 1500–9000 GPD)

Permeate Flow: 0.25–1.5 m³/h (4–70 TPD)

Feed Water TDS: <1500 ppm

Desalination Rate: 99%–99.8%

pH Range: 4–10

Silt Density Index (SDI): <2.8

Dissolved Iron: <0.1 mg/L

Voltage: 220V/380V or Customized

Dimensions: 700×650×1650mm (Standard, varies by model)



Product Highlights

✔ High Efficiency: 99%+ desalination rate for purified water.

✔ Flexible Configuration: Skid-mounted design, customizable flow/pressure.

✔ Wide Compatibility: Suitable for food processing, beverage, pharmaceuticals, and industrial water reuse.

✔ Low Maintenance: Easy-access components, durable SS304/SS316 materials.



Applications

Food & Beverage Processing

Safe Drinking Water Production

Plating/Wastewater Reuse

Power Plants & EDI Pre-treatment

Boiler Feed, Agriculture, Disaster Relief

System Models & Capacities



Small size RO system with 4" membranes

SRO-N series

Capacity

Power rate (50HZ)

RO membrane

width*depth*height

feed water TDS<1500ppm

(1-6 pcs)

mm

SRO-N-1500

1500gpd

0.25m3/h

1.5kw

4040

700*650*1650

SRO-N-3000

3000gpd

0.50m3/h

1.5kw

4040

700*650*1650

SRO-N-4500

4500gpd

0.75m3/h

1.5kw

4040

700*650*1650

SRO-N-6000

6000gpd

1.00m3/h

1.5kw

4040

700*650*1650

SRO-N-9000

9000gpd

1.50m3/h

2.2kw

4040

700*650*1650



RO water filter system 0.25tph SRO-R series 9000gpd

SRO-R series

Capacity

Power rate (50HZ)

RO membrane

width*depth*height

feed water TDS<1500ppm

(1-6 pcs)

mm

SRO-R-6000

6000gpd

1.00m3/h

1.5kw

4040

700*1650*1350

SRO-R-9000

9000gpd

1.50m3/h

2.2kw

4040

700*1650*1350

SRO-R-12000

12000gpd

2.00m3/h

3.0kw

4040

850*2350*1350

SRO-R-15000

15000gpd

2.50m3/h

3.0kw

4040

850*2350*1350



Certifications & Warranty

Certifications: CE, NSF, etc.

Warranty: 1-Year Limited Warranty


Pricing & Logistics

MOQ: 1 Set

Price: Negotiable

Delivery Time: 15–30 Days

Payment Terms: T/T, PayPal, Western Union

Packaging: Export Wooden Crate or Film-Wrapped

Supply Capacity: 50 Sets/Month


Why Choose Us?

Customized Solutions: Tailored to feed water quality and output needs.

Reliable Components: DOW/Hydronautics membranes, CNP pumps.

Global Service: Support for municipal, military, hospitals, and more.
