Key Specifications
Technology: Industrial & Commercial Reverse Osmosis (RO)
Design: Skid-Mounted, Compact
Capacity: 3000 GPD (Customizable 1500–9000 GPD)
Permeate Flow: 0.25–1.5 m³/h (4–70 TPD)
Feed Water TDS: <1500 ppm
Desalination Rate: 99%–99.8%
pH Range: 4–10
Silt Density Index (SDI): <2.8
Dissolved Iron: <0.1 mg/L
Voltage: 220V/380V or Customized
Dimensions: 700×650×1650mm (Standard, varies by model)
Product Highlights
✔ High Efficiency: 99%+ desalination rate for purified water.
✔ Flexible Configuration: Skid-mounted design, customizable flow/pressure.
✔ Wide Compatibility: Suitable for food processing, beverage, pharmaceuticals, and industrial water reuse.
✔ Low Maintenance: Easy-access components, durable SS304/SS316 materials.
Applications
Food & Beverage Processing
Safe Drinking Water Production
Plating/Wastewater Reuse
Power Plants & EDI Pre-treatment
Boiler Feed, Agriculture, Disaster Relief
System Models & Capacities
Small size RO system with 4" membranes |
SRO-N series | Capacity | Power rate (50HZ) | RO membrane | width*depth*height |
feed water TDS<1500ppm | (1-6 pcs) | mm |
SRO-N-1500 | 1500gpd | 0.25m3/h | 1.5kw | 4040 | 700*650*1650 |
SRO-N-3000 | 3000gpd | 0.50m3/h | 1.5kw | 4040 | 700*650*1650 |
SRO-N-4500 | 4500gpd | 0.75m3/h | 1.5kw | 4040 | 700*650*1650 |
SRO-N-6000 | 6000gpd | 1.00m3/h | 1.5kw | 4040 | 700*650*1650 |
SRO-N-9000 | 9000gpd | 1.50m3/h | 2.2kw | 4040 | 700*650*1650 |
RO water filter system 0.25tph SRO-R series 9000gpd |
SRO-R series | Capacity | Power rate (50HZ) | RO membrane | width*depth*height |
feed water TDS<1500ppm | (1-6 pcs) | mm |
SRO-R-6000 | 6000gpd | 1.00m3/h | 1.5kw | 4040 | 700*1650*1350 |
SRO-R-9000 | 9000gpd | 1.50m3/h | 2.2kw | 4040 | 700*1650*1350 |
SRO-R-12000 | 12000gpd | 2.00m3/h | 3.0kw | 4040 | 850*2350*1350 |
SRO-R-15000 | 15000gpd | 2.50m3/h | 3.0kw | 4040 | 850*2350*1350 |
Certifications & Warranty
Certifications: CE, NSF, etc.
Warranty: 1-Year Limited Warranty
Pricing & Logistics
MOQ: 1 Set
Price: Negotiable
Delivery Time: 15–30 Days
Payment Terms: T/T, PayPal, Western Union
Packaging: Export Wooden Crate or Film-Wrapped
Supply Capacity: 50 Sets/Month
Why Choose Us?
Customized Solutions: Tailored to feed water quality and output needs.
Reliable Components: DOW/Hydronautics membranes, CNP pumps.
Global Service: Support for municipal, military, hospitals, and more.
Contact Us for OEM/ODM Requests!
