5000ppm Turbidity Removed 3000 GPD Reverse Osmosis System
Overview:The 5000ppm Turbidity Removed 3000 GPD Reverse Osmosis System is a high-efficiency water purification solution designed for commercial and industrial applications. This system is ideal for purifying water with high turbidity and TDS (total dissolved solids) levels, offering reliable filtrat
Overview:
The 5000ppm Turbidity Removed 3000 GPD Reverse Osmosis System is a high-efficiency water purification solution designed for commercial and industrial applications. This system is ideal for purifying water with high turbidity and TDS (total dissolved solids) levels, offering reliable filtration and desalination for various sectors, including food and beverage, pharmaceutical, agriculture, and municipal water treatment. The system is engineered to handle feed water with a TDS of up to 5000ppm, ensuring high-quality purified water with a desalination rate of up to 99%.
Key Features:
High Turbidity Removal: Efficiently removes up to 5000ppm turbidity, making it ideal for treating water with high particulate matter.
Compact & Skid-Mounted Design: Easy to install and deploy, the skid-mounted design allows for flexible integration into various industrial setups.
Energy Efficient: Uses low power consumption with a motor rating of 1.5kW, ensuring both cost and energy savings.
Wide Application Range: Perfect for use in industries like municipal water treatment, food and beverage production, pharmaceutical, and mining.
High Desalination Efficiency: Achieves a desalination rate of up to 99%, ensuring high-quality water output.
Durable Construction: Made with high-quality stainless steel and other durable materials for long-lasting performance.
System Specifications:
Recovery Rate: 60-70%
Feed TDS: <2000 ppm
Water Temperature: 5-40°C
pH Tolerance: 4-8
Function: Water Purification, Desalination
Membrane Type: Vontron, Hydranautics, or DOW 4040
Capacity: 3000 GPD (11,355 Liters per day)
Application: Water filtration, drinking water, food and beverage, pharmaceutical, industrial water treatment
Control Options: Manual, electronic, or PLC-based control systems
Model Options:
| Model | Capacity (GPD) | Flow (m³/h) | Power Rating (50HZ) | Membrane Type | Dimensions (L x W x H) |
|---|---|---|---|---|---|
| SRO-N-1500 | 1500 GPD | 0.25 m³/h | 1.5 kW | 4040 | 700x650x1650 mm |
| SRO-N-3000 | 3000 GPD | 0.50 m³/h | 1.5 kW | 4040 | 700x650x1650 mm |
| SRO-N-4500 | 4500 GPD | 0.75 m³/h | 1.5 kW | 4040 | 700x650x1650 mm |
| SRO-N-6000 | 6000 GPD | 1.00 m³/h | 1.5 kW | 4040 | 700x650x1650 mm |
| SRO-N-9000 | 9000 GPD | 1.50 m³/h | 2.2 kW | 4040 | 700x650x1650 mm |
Applications:
Municipal Water Treatment: Provides efficient filtration for urban water systems.
Wastewater Treatment: Ideal for purifying wastewater in industrial facilities.
Food and Beverage Industry: Ensures clean water for production and processing.
Pharmaceuticals: Provides ultra-pure water required for manufacturing medicines and healthcare products.
Mining Industry: Suitable for treating water used in mining operations.
Agriculture: Ideal for irrigation water treatment and ensuring safe water for crops.
Boiler Feed Water: Ideal for generating high-quality feed water for boilers in various industries.
Emergency Water Supply: Can be deployed in disaster relief operations to provide purified water.
System Features:
Membrane Elements: LP21-4040 from Vontron, Hydranautics, or DOW, providing excellent performance and high salt rejection (99%-99.6%).
Cartridge Filtration: Equipped with 4.5” x 20” filters (5-micron) for pre-treatment, ensuring long membrane life.
Skid-Mounted Design: Easy installation and mobility, with an integrated system for fast setup and operational efficiency.
Boost Pump: Vertical multistage centrifugal pump made of SS304/SS316/Carbon steel for high pressure and efficiency.
Optional Features:
Stainless steel pressure vessels
High-pressure switches
pH or ORP meters
Automatic flushing system
Media filters, UV sterilizers, or Ozonation systems
Solar-powered systems for off-grid locations
Why Choose Fenigal’s 5000ppm Turbidity Removed 3000 GPD Reverse Osmosis System?
Fenigal offers high-performance reverse osmosis systems with customizable options for a wide range of commercial and industrial applications. Our 3000 GPD RO system is designed to handle high turbidity water, providing you with consistent, high-quality purified water. With advanced features like low energy consumption, high desalination rates, and reliable filtration, Fenigal ensures that you have the best solution for your water treatment needs.
